Italy Refcomp SPH SPL series Refcomp semi hermetic piston compressor

Italy Refcomp SPH SPL series Refcomp semi hermetic piston compressor

FOB Price:

Open price

Min.Order Quantity:

1 Piece/Pieces

Port:

Place of Origin:

Italy

Payment Terms:

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Brand:

Refcomp

Products Model:

SRCxxx

Products Details
Company Profile

Quick Details

Brand Name: Refcomp

Model Number: SRCxxx

Place of Origin: Italy

Packaging & Delivery

Packaging Details: export wooden pallet
Delivery Detail: 20 days

Specifications

SRC series air conditioning Refcomp semi-hermetic compact screw compressor

Specifications

-Refcomp SRC screw compressor,R22,R134a,R404a
-High efficiency,low noise
-used for air conditioning,chiller
-European quality

(Original Italy brand Refcomp semi-hermetic compact screw compressor which are made in China.large evaporating range,large cooling capacity,lower power comsuption, High efficiency,low noise,low vibration,easy for installation.High quality compressor internal parts.Used for air conditioning and chiller.European quality and reasonable prices)

Functionality:

High efficiency oil separation system

Sound lower and vibrations extremely low

Improved compression process

Step or stepless capacity control

Extent of delivery:

Y/ D motor(400V-3-50HZ,460V-3-50HZ) with 6TC temperature sensors,suction shut-off valve,discharge shut-off valve,intergrated check valve, intergrated safety relief valve,flanged-on oil separator,oil sight glass,oil filter,oil charge.Oil heater,4 steps capacity control(100-75-50-min%) or stepless(100-min%) motor protection moudle RCX-A(220V-1-50/60HZ),electrical box with enclosure class IP54,Nitrogen protective charge,kit oil cooling connection(only on SRC-XS-040/050/060,SRC-S-255/285/305/755/785/885/985),Vibration dampers kits.

SRC-S(W) series screw compressors

Model	Voltage	Displacement	Oil discharge	Max Operating current	Cooling capacity(KW)					Connection(")		Weight
		Displacement	Oil discharge	Max Operating current	Evaporating temperature(°C)					Connection(")		Weight
		M³/H	dm³	A	-10	-5	0	2	5	Suction	Discharge	KG
SRC-XS-040	400V/3PH/50HZ-460V/3PH/60HZ	118	6.5	80	55.8	70.5	87.9	95.7	108.1	2-1/8"	1-5/8"	300
SRC-XS-050	400V/3PH/50HZ-460V/3PH/60HZ	150	6.5	90	70.9	89.6	111.8	121.6	137.4	2-1/8"	1-5/8"	305
SRC-XS-060	400V/3PH/50HZ-460V/3PH/60HZ	175	6.5	96	82.8	103.6	127.4	137.8	154.1	2-1/8"	1-5/8"	310
SRC-S(W)-113	400V/3PH/50HZ-460V/3PH/60HZ	118	6	80	55.8	70.5	87.9	95.7	108.1	2-1/8"	1-5/8"	325
SRC-S(W)-133	400V/3PH/50HZ-460V/3PH/60HZ	150	6	90	70.9	89.6	111.8	121.6	137.4	2-1/8"	1-5/8"	330
SRC-S(W)-163	400V/3PH/50HZ-460V/3PH/60HZ	175	6	96	82.8	103.6	127.4	137.8	154.1	2-1/8"	1-5/8"	335
SRC-S(W)-183	400V/3PH/50HZ-460V/3PH/60HZ	205	7	124	96	120.2	147.8	159.8	178.7	2-5/8"	2-1/8"	510
SRC-S(W)-213	400V/3PH/50HZ-460V/3PH/60HZ	237	7	140	110.9	138.9	170.8	184.5	206.6	2-5/8"	2-1/8"	515
SRC-S(W)-255	400V/3PH/50HZ-460V/3PH/60HZ	286	10	168	136.4	170.8	210	227.2	254	3-1/8"	2-1/8"	615
SRC-S(W)-285	400V/3PH/50HZ-460V/3PH/60HZ	318	10	192	151.8	190.2	233.6	252.6	282.7	3-1/8"	2-1/8"	590
SRC-S(W)-305	400V/3PH/50HZ-460V/3PH/60HZ	341	10	196	164.2	205.6	253	273.5	306	3-1/8"	2-1/8"	625
SRC-S(W)-353	400V/3PH/50HZ-460V/3PH/60HZ	402	14	225	195.6	245.1	301.5	325.8	364.5	3-5/8"	3-1/8"	730
SRC-S(W)-413	400V/3PH/50HZ-460V/3PH/60HZ	445	14	245	218.6	273.9	336.6	364	407.3	3-5/8"	3-1/8"	740
SRC-S(W)-463	400V/3PH/50HZ-460V/3PH/60HZ	510	16	270	240.1	303.8	378	410.6	462.8	3-5/8"	3-1/8"	775
SRC-S(W)-503	400V/3PH/50HZ-460V/3PH/60HZ	562	19	300	264.6	334.8	416.4	452.5	509.6	4-1/8"	3-1/8"	1010
SRC-S(W)-553	400V/3PH/50HZ-460V/3PH/60HZ	600	19	334	282.4	357.4	444.5	483.2	544.3	4-1/8"	3-1/8"	1030
SRC-S(W)-603	400V/3PH/50HZ-460V/3PH/60HZ	700	20	400	365.8	446	537.6	577	639.6	4-1/8"	3-1/8"	1020
SRC-S(W)-755	400V/3PH/50HZ-460V/3PH/60HZ	860	23	418	389.6	487.2	594	638.8	712.8	4-1/8"	3-1/8"	980
SRC-S(W)-785	400V/3PH/50HZ-460V/3PH/60HZ	910	25	520	506.1	617.4	743.6	798.5	885.4	134.8	4-1/8"	1400
SRC-S(W)-885	400V/3PH/50HZ-460V/3PH/60HZ	1000	25	590	571.4	696.8	839.6	901.6	999.8	134.8	4-1/8"	1400
SRC-S(W)-985	400V/3PH/50HZ-460V/3PH/60HZ	1100	25	650	638.4	778.1	937.4	1006.8	1116.5	134.8	4-1/8"	1400
TEST CONDITION:Condensing Temperature: 50°C

"ISO9001, CE & RoHS Compliance, Quality and Cost Management"

We provide practical, reliable and inexpensive various refrigeration equipments, such as ice making machines, cold room equipments, Condensing Units, Air Coolers, Condensers, insulation panels with CE and RoHS certificate for worldwide markets. Furthermore, a factory direct supplying model will bring more profits to you.

Taizhou Best Refrigeration Equipment Manufacturing Co.Ltd. was founded in Taizhou City in 2009, dedicated to producing refrigeration equipments, such as condensing units, air coolers , ice machines, cold room panels with our famous brand - "LIIk". 60% of the products are exported to the USA, Europe and the Middle East directly.40% are sold in domestic markets. Our original company is located in Shanghai which is named "Shanghai maolai Industry&Supplying Co.,Ltd.".Shanghai company is established in 2003.Benefiting from our efficient quality management and cost control system, we can make products practical, reliable and inexpensive for worldwide markets.

We passed ISO9001, CE and RoHS certification. Eventually, we are committed to establishing a way of "factory-to-consumer, factory-to-distributor" to reduce your costs and seek for win-win cooperation.
